Elliptical Waveguide - VT26EWAL
Elliptical Waveguide
| MODEL NO |
VT26EWAL |
| FREQ RANGE (GHz) |
2.5-2.7 |
| VSWR Max |
1.25 |
| ATTENUATION (dB/100 m) |
3.0 |
| PEAK POWRE (kW) |
460 |
| BEND RADIUS (E Plane) Min (mm) |
600 |
| BEND RADIUS (H Plane) Min (mm) |
1500 |
| EXTERNAL DIAMETER (mm) |
108.4×61.3 |
| MATERIAL |
Corrugated Copper |
| WEIGHT (kg/m) |
2.5 |
* Please refer to the Technical Reference section for flange types/connectors details.The outline drawings shown are standard versions. Please contact us for your specific requirements. |
Vector Telecom offers a wide selection of Elliptical Waveguide for feeder of most microwave antenna systems in 3 to 20 GHz frequency range. All elliptical waveguide is jacketed unless otherwise specified. Customized length, splice and other accessories are available upon request.
| |
